2 Phase Stepper Motor

Your Leading 2 Phase Stepper Motor Supplier

XFOYO is a national high-tech enterprise focusing on the research and development, production and sales of motion control products. Our company mainly develops and produces stepper motor, stepper driver, servo motor, servo driver, brushless motors, brushless driver and motion controllers, PLC, HMI and other products. 2 phase stepper motors, known for their precision and reliability, are widely used in applications requiring accurate positioning and motion control, such as in CNC machines, 3D printers, robotics, and automated manufacturing.

Why Choose Us?

Rich Experience

SHENZHEN XFOYO ELECTRIC CO., LTD. is established in 2009, is a national high-tech enterprise focusing on the research and development, production and sales of motion control products.

Quality Guaranteed

All XFOYO products have passed CE, FCC, UL, RoHS and other certifications, and professional quality management personnel conduct product testing to ensure product quality.

Wide Product Range

XFOYO products are widely used in semiconductor equipment, robots, medical equipment, textile equipment, digital post printing equipment, clothing plotters, packaging machinery, carving machines, sewing equipment, laser equipment and other industries.

Broad Market

All products manufactured by the factory are exported to over 20 countries, and original equipment manufacturing (OEM) services are also available upon request.

Types of 2 Phase Stepper Motor

2 Phase Nema 8 Hybrid Stepper Motor

2 Phase Nema 8 Hybrid Stepper Motor achieves low control costs and can operate in an open-loop control system, operating in any environment. The motor's rotation angle is proportional to the input pulse.

2 Phase Nema 14 Hybrid Stepper Motor

2 Phase Nema 14 Hybrid Stepper Motor has the advantages of durability, high reliability, high torque, and low maintenance. 2 Phase Nema 14 Hybrid Stepper Motor is widely used in electronic equipment, cutting machines, marking machines, packaging machinery, and other equipment, and is the preferred choice of motor for users.

2 Phase Nema 23 Hybrid Stepper Motor

2 Phase Nema 23 Hybrid Stepper Motor can achieve high-frequency start and stop, fast response speed, innovative heat dissipation technology, and fast heat dissipation.

2 Phase Nema 42 Hybrid Stepper Motor

2 Phase Nema 42 Hybrid Stepper Motor uses imported materials to ensure stable and reliable motor performance, and a strict quality control system ensures product consistency. 2 Phase Nema 42 Hybrid Stepper Motor is suitable for automated assembly equipment, laser typesetting, semiconductor and other equipment.

Specifications of 2 Phase Stepper Motor

Model	Step Angle (°)	Motor Length	Holding Torque		Rated Current (A)	Phase Resistance (Ω)	Phase Inductance (mH)	Rotor Inertia (g.cm²)	Weight (Kg)	Wires
Model	Step Angle (°)	(mm)	N.m	Oz/in	Rated Current (A)	Phase Resistance (Ω)	Phase Inductance (mH)	Rotor Inertia (g.cm²)	Weight (Kg)	Wires
FY28ES080A	1.8	32	0.06	8.57	0.8	5.3	3.3	8	0.1	4
FY28EM080A	1.8	41	0.08	11.42	0.8	7.8	5.4	11	0.15	4
FY28EL080A	1.8	48	0.09	12.85	0.8	7.2	5.1	13	0.2	4

Functions of 2 Phase Stepper Motor

It is widely used due to its high resolution (generally the step angle is 1.8°).
Turn huge.
Compare with multi-phase hybrid stepper motor. Driving power tubes are used in large quantities but are cheap.

Customization Options

Material:

Customizable

Color:

Customizable

Style:

Customizable

Warranty period:

One year

Logo:

Can print your private logo as per your requirement

Minimum order quantity:

We have flexible minimum order quantity

Delivery time:

7 days after order confirmation

Packing:

Carton (Customizable with special requirements)

Installation Requirements of 2 Phase Stepper Motor

Connect the Stepper Motor to the Driver:

Follow the driver's documentation for the correct wiring connections.

Connect the Driver to the Power Supply:

Ensure the driver's voltage and current ratings are compatible with the power supply.

Connect the Driver to the Microcontroller (if using):

Connect the driver's control pins (enable, direction, step) to the microcontroller's digital pins.

Usage of 2 Phase Stepper Motor

3D Printing:

Accurate Motion Management: 2-phase steppers propel the X, Y, and Z axes, ensuring meticulous layer-by-layer printing precision.

Computer Numerical Control (CNC) Machines:

Regulated Milling and Cutting: Steppers govern the movement of cutting tools in CNC machines, facilitating intricate designs and exact cuts.

Automation:

Articulated Robot Joints: Steppers in robotic joints provide controlled movement and precise positioning for diverse actions and tasks.

Medical Equipment:

Diagnostic Instruments: Steppers in medical devices, such as syringes and pumps, guarantee precise dosage control and seamless operation.

Surveillance Systems:

Camera Pan-Tilt Mechanisms: Steppers in surveillance cameras facilitate controlled pan and tilt movements for comprehensive monitoring.

Office Technology:

Paper Feeders and Scanners: Steppers precisely manage paper movement in printers, scanners, and other office apparatus.

DIY and Recreational Projects:

3D Printer Enhancements and DIY Robotics: Enthusiasts leverage 2-phase steppers for customized ventures like 3D printer upgrades and DIY robotic creations.

Music Instruments:

Electronic Drum Pads and Synthesizers: Steppers integrated into electronic drums and synthesizers offer tactile feedback and accurate control, enhancing the authenticity of playing experiences.

Automotive Sector:

Mirror Adjustment and Valve Control: Automobile steppers regulate functions such as mirror adjustment and valve timing with precision and dependability.

Certificate

productcate-1-1

Order & Production Process

Depends on whether you want to do customization your product or not, and also depends on the speed of customs clearance and logistics, but we can guarantee to ship regular product in less than 2 business weeks.

01.

Specs & Custom

Confirm product specs and custom details with our experts. This can be all settled within an hour.

02.

Confirm & Payment

After all details are set, make transfer of advance payment. Normally, it takes 1 day or 2 to arrive our bank account.

03.

Production & Inspection

After payment, production will be arranged right away and we'll keep you updated. Usually it 2-3 weeks before shipping.

04.

Balance & Shipping

We will send you details of products and packing before shipping. All products can be delivered to port at the same day.

Shipping & Payment

productcate-1-1

FAQ

Q: How much voltage can a 2 phase stepper motor handle?

A: It depends on the chip set or application design, but most logic supplies are in the 5 volt range. The motor power supply is the supply voltage to power the motor. This voltage level is usually in the 24 VDC range but can be much higher.

Q: Can 2 phase stepper motors get wet?

A: Automation of industrial processes often requires automation equipment to operate in the presence of water and aqueous fluids. Step motors are prone to short term failure in these conditions because they have several water entry point that make sealing virtually impossible.

Q: What is the torque in a 2 phase stepper motor?

A: 2 phase stepper motors feature both static and dynamic torques. Static torque is the torque that a motor can produce when it is not rotating; In stepper motors, holding torque and detent torque are referred to as static torques. Conversely, dynamic torque is the torque that a motor can produce in rotating conditions.

Q: Do 2 phase stepper motors lose power over time?

A: Some stepper motors run without fault for a long time before the first step losses occur. In such cases, it is highly likely that the load has changed. This can on the one hand indicate wear of the motor bearings.

Q: How reliable are 2 phase stepper motors?

A: 2 phase stepper motors are very reliable since there are no contact brushes in the motor. Therefore, the life of the motor is simply dependent on the life of the shaft bearing.

Q: What can damage a 2 phase stepper motor?

A: The level between the stepper motor and the load is not adjusted properly, causing the load and the stepper motor to be out of center and causing radial impact force.
The screws of the stepper motor feet are not fixed properly, or the fixing frame is not designed well.

Q: What is the safe temperature for a 2 phase stepper motor?

A: Anything below 175F (continous) is considered safe for most steppers. Even idling steppers can feel warm, because power is used to keep them stationary.
